SMD Indoor Sensor LED Batten
The S-Tech SMD Indoor Sensor Batten (SMD-4FT-4C-M) is a versatile LED batten designed for indoor commercial and residential applications. With built-in microwave motion sensing and 4 selectable colour temperatures (3000K/4000K/5000K/6000K), this batten offers flexible illumination and energy-saving control.
The microwave sensor is optional and configurable via dip switches, removing the need for remote programming. The 3-step dimming function (on-dim-off) allows the batten to operate at standby dim level until motion is detected, providing automatic full brightness when needed. Ideal for corridors, storage areas, offices, or workshops, the SMD Indoor Sensor Batten is both efficient and adaptable.
Product Features
Model: SMD-4FT-4C-M
-
Watt Select: 36W/30W/20W
-
4 colour adjustable: 3000K/4000K/5000K/6000K
-
Built-in microwave sensor with 3-step dimming: On – Dim – Off
-
Sensor configurable via dip switches (no remote required)
- Sensor can be disabled for standard batten operation
-
Lumen Output: 4140–4533lm (36W)
-
Centre or side cable entry, 20mm knock-outs for continuous fixing
-
Input: 220–240VAC
-
Beam Angle: 120°
-
Polycarbonate opal diffuser
-
Powder-coated steel base
-
IP20 rated housing
-
Dimensions: 1200 x 65 x 60mm
-
Default factory settings:
-
CCT: 4000K
-
Sensor Detection Area: 100%
-
Hold Time: 60 seconds
-
Daylight Sensor: Disabled
-
Standby DIM Level: 20%
-
Standby Period: Infinity
-
Functionality: The batten will remain at 20% brightness day and night, and switch to 100% brightness for 60 seconds when motion is detected. Multiple sensor settings are available; see specification sheet for options.
